Karn Map Screenshots
Karn Map Details
Karn Map is an educational application that offers several tools to simplify logic functions.Automatic Veitch Karnaugh maps simplification is available for 3 to 5 variable logic functions. Functions can also be input by its logical expression, truth table, sum of minterms, or product of maxterms. In addition, a schematic based on a AND-OR plane can be obtained for 3 to 7 variable functions.
The tool also includes a binary-octal-decimal-hexadecimal converter.
Free and offline App
Topics:
- Veitch-Karnaugh maps
- From 3 to 7 variables
- Truth tables
- Sum of minterms
- Product of maxterms
- Logic expressions
- AND-OR planeschematic
- Converter
- Binary
- Octal
- Decimal
- Hexadecimal
- Tutorial
- Help
